What Class CDL Do I Need? CDL Class Finder

Part of Driver Files & Medical

The class on a CDL is set by weight ratings, seats and placards, not by how big the truck looks. Put in the numbers from the door label and the trailer plate and this tells you which of the three classes the rig needs, or whether it needs one at all, plus any endorsements those same inputs trigger.

Which class this rig needs

Pre-filled with a hotshot pickup and gooseneck. Use the ratings on the plates and door labels, not what the load weighed today.

You need

Class A

The towed unit is rated 21,000 lb, over the 10,000 lb line, and the combination rates 35,000 lb, at or over 26,001 lb. That is a combination vehicle under §383.91(a)(1).

GCWR that counts
35,000 lb
Section
§383.91(a)(1)

First time at this class or endorsement? Entry-level driver training from a provider on FMCSA's Training Provider Registry comes before the test.

Low-poly render of a truck in a training yard with cones
A training-yard truck. Its class comes from the rating plate, not from its size.

What it checks

Three questions, asked in the order the regulation asks them. Is it a combination over 26,001 lb towing more than 10,000 lb? Class A. If not, is the power unit itself rated 26,001 lb or more? Class B. If neither, does it seat 16 or more including the driver, or carry placarded hazmat? Class C. Anything left over needs no CDL under federal rules.

The step most people get wrong is the combination rating. Under §383.5 the GCWR is the greater of the figure on the truck's label and the trailer and truck ratings added together. A pickup labelled for 30,000 lb pulling a gooseneck plated for 21,000 counts at 35,000. That is the case that most often catches hotshot setups out.

It also flags endorsements: T for doubles or triples, P for 16+ seats, H for placarded hazmat, N for a tank vehicle (tanks over 119 gal each and 1,000 gal or more in total), and X when H and N stack. School-bus work needs S, which no weight input can detect. The CDL requirements guide covers what each endorsement takes to earn.

Worked example

Seven rigs, run through the same rules as the finder. The second and third rows are the ones worth showing a new hire: a heavy trailer behind a light truck, and a rental box truck rated one pound under the Class B line.

RigPower GVWRTowed GVWRGCWR that countsResult
Hotshot pickup and gooseneck (label GCWR 30,000)14,00021,00035,000Class A
Same pickup, 10,000 lb bumper-pull14,00010,00024,000No CDL needed
Rental box truck rated 26,00026,000026,000No CDL needed
Dump truck, 10,000 lb equipment trailer33,00010,00043,000Class B
Dump truck, 14,000 lb tag trailer33,00014,00047,000Class A
Shuttle bus, 20 seats14,500014,500Class C + P
Tractor pulling two pups33,00056,00089,000Class A + T

A truck that needs no CDL can still be a commercial vehicle for the other rules. Across state lines, the medical card and the hours-of-service limits reach a lot further down the weight range than the licence does, and the USDOT number usually follows the same lower line.

The rule it comes from

49 CFR §383.91(a) defines the three groups: Group A, combination vehicle; Group B, heavy straight vehicle; Group C, small vehicle. §383.5 defines the CMV, the GCWR and the tank vehicle. §383.93 lists the endorsements and §383.153 their codes.

Two exceptions the finder does not model. §383.3 exempts drivers operating CMVs for military purposes, and lets each state waive the CDL for certain farm vehicles, firefighters and emergency vehicles, and some snow and ice removal by local government. If one of those might be you, check with your state licensing agency. And a Class A or B learner, or anyone adding P, S or H for the first time, has to finish entry-level driver training under §380.609 before testing.
